PR9200 small UHF RFID Reader writer Module with usb serial ports rs232 wiegand26 wiegand34

PR9200 small UHF RFID Reader writer Module with usb serial ports rs232 wiegand26 wiegand34

Model number:CZS6147




has an outstanding performance with Low-Power


◆No heat during long-term continuous full load working atroom temperature.

◆Continuous Current<200mA/3.5V(26 dBm Output).

◆Continuous Current<110mA/3.5V(18 dBm Output).

◆Supports USB powered.◆Supports independent power supply.

Supports two installation methods:

◆Can be used as a Desktop Reader.

◆Can be wall-mounted, used as Access Control.


Model Number and Size

CZS6147 , size with board: 61*47*12mm, without board: 28*25.5*2.5mm


902Mhz – 928Mhz     or   865MHz – 868MHz

chipPR9200 chip

Reading   Distance

1cm-15meters (depending on application/ reader/antenna/install sites),

if work with 40*40 ceramic uhf antenna(like first picture) ,read range about 1cm- 3m


 usb ,RS232 /Wiegand 26 /Wiegand 34(optional)

Baud rate

115200 bps(default and recommended)     38400bps

Supply   Voltage

USB (5V), supply power 9v

Air   Interface Protocol

EPC global UHF Class 1 Gen 2 / ISO 18000-6C

Output Power


Read multi-tag

1- 50 Tag/Second

Tag   cache

200 Tags@ 96 bit EPC

low power  consumption

Sustained current <200mA / 3.5V (26 dBm Output)

Sustained current <110mA / 3.5V (18 dBm Output)

Operating   Temperature

- 20 °C           -    + 70    °C

Storage   Temperature

- 20 °C           -    + 85     °C


< 95% ( + 25 °C)

Output Power Precision

+/- 1dB

Output   Power Flatness

+/- 0.2dB

Receiver   Sensitivity

< -70dBm



Heat Dissipation

No heat sink required
